Model CVC1220, Hi Speed Electronic Channel Counter
The CVC1220 Electronic Channel Counter is designed for high speed, highly accurate counting of tablets, capsules, and soft gels. The machine comes standard with an automatic dust compensation system, dual vacuum ports, product count verification, and reject. The 1220 can be setup to run one bottle using all 12 channels or two bottles using 8 channels for each bottle. Options include touch screen industrial PC, hopper level control with tower Lamp, upside down bottle sensor, static eliminator bar, channel blocker, and floor loaded pre feeder.
- Built to cGMP Standards
- Stainless Steel Construction
- 50 Channels of Memory
- Quick & Easy Change Over
Request Product Updates
Standard Features
- 12 V-Shaped Channels per head, tool less change over
- Auto Dust Compensation
- Dual Dust Extraction Ports
- Powered Height Adjustment
- Track Full / Track Empty Sensors
- 2.83M-Motorized Single Lane Sanitary Conveyor (single head)
- 4.95M-Motorized Dual Lane Sanitary Conveyor (dual head)
- Pneumatic gating & plow reject for over / under count
- Memory capacity for 50 jobs
- Stainless Steel Construction
- Capacity: up to 55 Bottles per minute (BPM) on a count up to 100 products.
- ISO 9001:2000 Certified
Machine Specifications
| Standards | FDA Approved Contact Materials |
Air/Electrical Requirements
| Power | 220 V |
| Frequency | 50/60 Hz |
| Phase | Single |
| Power Consumption | 6 A |
Options
| Available Options | Channel Blocker Container up side down or fallen sensor Floor Loaded Pre-Feeder with Integrated Controls Hopper level control system with tower lamp Industrial PC, Windows XP, Touch Screen Static Eliminator Bar |
Specification Notes
| Note | Dimensions shown are for a standard machine. The 1220 Single or Dual Head Counter must be purchased with either a single or dual lane conveyor as shown. This machine can run independently or can be integrated into an automatedpackaging line. All CVC equipment is covered by a one year parts warranty. Full Warranty details are included in our equipment proposals or can be found on our website. |
