Model CVC300, Wrap Labeler
The CVC300 Wrap Labeler is built to automatically apply pressure sensitive labels onto round containers. It is an ideal machine for contract packagers and manufacturers serving the nutraceutical, food, cosmetic, personal care, and household product markets.
All CVC labelers include our patented Self Set™ software which utilizes a high frequency encoder for extremely easy setup and wrinkle free labeling at the touch of a button.
Request Product Updates
Standard Features
- Self Set Auto Adjusting Control System
- Stainless Steel Frame on lockable casters
- Stainless Steel flat bed conveyor with 4″ wide table top chain (Raised Sanitary Bed)
- 25-Key Hand Held Terminal with LCD Display
- Label head with up to ± 1/32″ accuracy and Integrated Wrap Station
- Label Sensor for Paper or Opaque Labels
- Product Sensor with Opaque and Clear Bottle Mode
- Variable Speed Separator Wheel
- Capacity: up to 170 bottles per minute (BPM)
- ISO 9001:2000 Certified
Container Specifications
| Bottle Height | 1 to 12 in 25 to 305 mm |
| Bottle Diameter | 1 to 7 in 25 to 178 mm |
Label Specifications
| Label Width/Height1 | 3/8 to 9 in 16 to 152 mm |
| Label Length | 5/8 to 12 in 16 to 305 mm |
| Maximum Label Roll2 | 14 in 356 mm |
| Maximum Label Head Dispense Speed | 38 m/min |
1 Dependent on labeling head type.
2 2 Outside diameter with 3″ core
Machine Specifications
| Conveyor Width | 4 in (Standard) 4-1/2 in (Optional 6 in (Standard) |
| Conveyor Length | 79 in (Standard) 94 in (Sanitary) (Optional |
| Conveyor Bed Height | 36 in (± 2 in) (Standard) |
| Machine Weight | 130 kg 180 kg 800 kg |
Air/Electrical Requirements
| Power | 110 V (Standard) 208 V (Optional) |
| Conveyor Length | Single |
| Conveyor Bed Height | 6 A |
| Air Consumption Air Consumption Only required when using Lot/Date Printer |
4 ft3/min |
Available Options
| Printing Printing Hot Stamp (Lot/Date Coding) Print Area: 2-3/4 in (70 mm) W x 2-1/2 in (65 mm) H Type Sizes: 1.5 mm, 2.0 mm, or 2.5 mm Chase Size: 6 Lines of 13-22 Characters each Low Ribbon Sensor |
Hot Stamp (Lot/Date Coding) Integrated Thermal Encoder (Lot/Date, Bar Code and Graphics) |
| Assemblies | Adjustable Tilt for Tapered Bottles Clear Label Sensor Custom Wrap Belts Feed Screw Infeed and Outfeed Conveyor Extensions Loading and Collecting Turn Tables Low Label Sensor (Factory Installed Only) Raised Sanitary Bed Conveyor |
Specification Notes
| Note | Dimensions shown are for standard machine. Conveyor can be extended or length may vary based on options selected. This labeler can run independently or be integrated into an automated packaging line. |
