ATH Vertical Tray Former
IPAK’s ATH fully automatic tray former features a compact, vertical design that is ideal for packagers with minimal plant space. The ATH is able to form a variety of trays including 4-corner trays, one piece telescope (clamshell), econo tray, bag-in-box styles, MUB style trays, HSC lidding and more. The versatility of this machine makes it ideal for operations forming a variety of different trays and tray styles.
Built with premium construction materials like anodized aluminum, stainless steel and other corrosion resistant materials, this robust machine is ideal for continuous around the clock operation. Similar to other IPAK machines, the ABH utilizes servo motors for minimal maintenance and precision tray forming. The ATH utilizes a fully featured HMI control system and safety features like interlocking guard doors and an auxiliary e-stop station.
Request Product Updates
Features
-
Compact VersatilityThe ATH is able to form a wide variety of tray styles with a compact machine footprint, making it adaptable to most plants and applications.
-
Reliable, Precision Tray FormingServo motors provide precise and accurate tray forming, ensuring each tray is properly formed with superior stacking strength and an ideal aesthetic.
-
Low Operational and Maintenance CostsServo drives require less energy and maintenance, providing long-term cost savings. Venturi style self cleaning vacuum cups also provide extended operation with minimal amounts of service required.
-
Safe OperationStandard interlocking safety guard doors provide a safe environment for operators.
-
Minimal Training RequiredWexxar’s WISE System which provides on board machine tuning and pictorial guides on machine faults and provides potential solutions when they occur.
Options
-
Machine Management with Tri-Light BeaconProvides both an audible and visual alarm to advise operators of low glue or low magazine to ensure continuous operation and avoid potential downtime.
-
Outfeed ConveyorsOutfeed conveyor provides a location to collect formed trays so they can be stacked or transported for loading or further processing.
-
Lidder AttachmentThe lidder option allows formed trays to be inserted into a lid for packing or further processing.
-
EZ-Load MagazineEZ-Load Magazine allows for trays to be quickly and conveniently loaded.
-
Nordson Glue System UpgradeUpgrade your glue system to provide advanced features such as glue stitching, on-demand melting and other cost saving benefits which help reduce glue and energy consumption.
Specifications
-
Speedup to 45 TPM (trays per minute)
-
ConstructionPremium heavy duty materials with a welded frame and EZ-clean powder coat for long lasting performance
-
AdhesionAvailable in hot melt
-
ControlsWISE System with HMI touchscreen interface
-
Country of ManufacturingDesigned and Built in Canada
