Model CVC1650/1651, Shrink Bundler & Heat Tunnel
The 1650/1651 Shrink Bundler & Heat Tunnel is a user friendly, compact machine designed to shrink bundle small and medium sized products. Machine options include multiple in-feed configurations and a single or double discharge depending upon rate requirements. The 1650/1651 is an ideal machine for the Nutraceutical, Pharmaceutical, Food and Beverage Markets.
- Built to cGMP Standards
- Painted Steel or Stainless Steel Construction
- Economical Value
- Quick & Easy Change Over
Request Product Updates
Standard Features
-
- Painted Steel or Stainless Steel Construction
- Single, indexing product loader and 2-Sided Sealer
- Integrated Heat Shrink Tunnel
- Quick product size changeover
- Machine on casters for ease of movement
- Light, compact design
- Rate: Dependent upon bottle matrix
Bundler Specifications
| Maximum Width (Single Product Loader) | 16 in 410 mm |
| Maximum Length (Single Product Loader) | 14 in 355 mm |
| Maximum Height (Single Product Loader) | 8-3/4 in 22 mm |
| Maximum Width (Double Product Loader) | 11-1/2 in 292 mm |
| Maximum Length (Double Product Loader) | 9-3/4 in 247 mm |
| Maximum Height (Double Product Loader) | 8-3/4 in 222 mm |
Film Roll Specifications
| Maximum Roll Width (Single Product Loader) | 20-1/2 in 520 mm |
| Maximum Roll Width (Double Product Loader) | 11 in 279 mm |
| Maximum Roll Outer Diameter (Double Product Loader) | 11-1/2 in 292 mm |
Machine Specifications
| Machine Weight | 992 lbs 450 kg |
| Machine Dimensions (W x L x H) | 86-1/2 x 108 x 63-1/2 in 2200 x 2750 x 1615 mm |
Options
| Options | 1.0M Outlet Gravity Roller Conveyor, SUS 304 Stainless Product Change Part Variable Speed Drive for In-feed conveyor |
Power and AirRequirements
| Power | 220 V |
| Frequency | 50/60 Hz |
| Phase | Three |
| Power Consumption Power Consumption Including Bundler and Heat Tunnel |
50 to 75 A |
| Minimum Air Pressure Minimum Air Pressure ISO 8573-1 |
87 psi |
| Air Volume Air Volume Plant air must be dry and clean |
280 L |
Specification Notes
| Note | Dimensions shown are for a standard machine. This machine can run independently or can be integrated into an automated packaging line. All CVC equipment is covered by a one year parts warranty. Full Warranty details are included in our equipment proposals or can be found on our website. |
